Description
Lab Scale Mini PV Module Laminator 700*700mm is most important machine to test new material for future technology of industry with electric heating.
Thanks to faster heating speed and less power consuption, Lab Scale Mini PV Module Laminator 700*700mm is acceptted by majority of solar module manufacturer or schools.
The lamination dimension with electric heating:400*500mm,400*400mm,500*500mm,700*700mm.
|
Model |
AZ-0707 | Laminate Length * Width | 700mm x700mm
|
|
Dimension |
1400×1000×1100mm | Weight |
700kg
|
|
Power supply |
380V 3 phase | Peak power |
18Kw
|
|
Pumping speed |
8L/S | Work power |
9Kw
|
|
Control mode |
Automatic/ Manual | Ultimate vacuum |
20 Pa
|
|
Heating mode |
Electrical heating system | Temperature control mode |
PID Control |
|
Maximum temperature |
180℃ | Temperature uniformity |
±3℃ Multi-point temperature control
|
|
Work temperature |
100℃～160℃ | Controllable temperature precise |
≤±3℃ (at the regulated set temperature value
|
|
Unevenness of the worktable |
Unevenness≤300 μm/m² | Air discharge speed |
Can adjust continuously within 0～50L/S
|
|
Press of compressed air |
0.5～0.8MPa | Laminate time |
about 15min. |
|
Pumping time |
4～5min | Compressed air speed |
1-8L/S |
|
Work vacuum degree |
80～20Pa | Ambient temperature |
0～50℃
|
|
Note: Customized specifications are available upon your requirements. |
|||
