Description
Solar cell tester is specially designed for the filtration of solar mono-crystalline silicon and poly-crystalline silicon cells.Through the stimulated light irradiation by the solar spectrum lamp-house,the machine classifies the solar cells according to the testing and surveys result with related electrical parameter of solar cells.
Unique apparatus to input and modify the compensate parameters, to carry on automatically/manual adjustment to the light and temperature compensation, as well as automatically measurement and modification of the temperature.
Based on the Windows operation interface and humanely designed testing software, it records data and displays test curve (I-V curve, P curve) and the test parameters (Voc, Isc, Pm, Im, FF, EFF). The test of sequence number is automatically produced and preserved to the assigned folder.
| Model | AZSCT-B |
| Light Simulation | |
| Sun Simulator | High-power Pulsed Xenon Lamp |
| Spectrum Range | Meet IEC60904-9 Requirement AM1.5 |
| Light Intensity | 100mW/Cm2 (Adjustment Range 70~120mW/Cm2) |
| Intensity Inhomogeneity | ≤±3% |
| Irradiation Instability | ≤±3% |
| Service Life of Xenon Lamp | 100,000 Flashing times(Imported) |
| Flash Counting Function | Function of counting the number of flashes(Reset to Zero after replaced) |
| Flashing Direction | Vertically Downwards |
| Test Area | |
| Effective Test Area | 200mm*200mm |
| Effective Test Range | 0.1W~5W |
| Test Voltage | 0V~0.8V(Resolution 1mV) Measuring Range 1/16384 |
| Test Current | 100mA~2A/20A(Resolution 1mA) Measuring Range 1/16384 |
| Test Temperature | 15℃~35℃(Resolution 0.1℃) |
| Test Accuracy | |
| Test Repeatability Accuracy | ≤±1% |
| Electrical Performance Measurement Error | ≤±2% |
| Test Way | Four-line Test |
| Test Parameters | Isc,Voc, Pmax, Vm, Im, FF, EFF, Temp, Rs, Rsh |
| Single Testing Time | 3 secs/pc |
| Data Acquisition | 2M, 4-channel synchronous high-speed acquisition card and more than 8,000 Points in I-V Curve to Collect Data |
| Test Condition Calibration | Automatic Calibration Device |
| Temperature Test | Automatic Temperature Test |
| Temperature Compensation Display | |
| Correct Test Temperature | |
| Test Result | Test Time and Graphical Parameters Display(I-V Curve) |
| It Can Convert Test Result to Standard Test Conditions | |
| Test Report | Voice Reporting&Prompt of Test Result |
| I-V Curve Can Be Recorded on Work Interface | |
| Test Results Can Be Saved to Specific Files of Hard Disk | |
| The Name of Specific Files Can Be Changed | |
| Data Aggregation&Print | Data Aggregation&Print at Any Time |
| Can Be Print Out with EXCEL File | |
| Professional Software | Coefficient Input of Temperature Compensation |
| Coefficient Input of Date and Name | |
| Serial Number Function | |
| Defective Parameters Setting | |
| Working Time | Can Work Continuously More Than 12 hrs |
| Power Supply | 220V/50Hz/2kW |
| Air Compressor Requirement | 0.6mPa~0.8mPa |
