Description
Solar panel laminator 1100*2200mm designed back opening is semi automatic type,oil heating with auto&manual mode for bulk production at factory.
The minimum solar panel laminated from few watt to 350W.
Contact AozeeSolar for more solar machines.
| Model | AZ-1122 | Laminate Length * Width | 1100mm x 2200mm |
| Dimension(mm) | 2500×1800×1200 | Weight(Kg) | 4000kg |
| Power supply | 380V 3 phase / 4wire | Peak power | 24 Kw |
| Pumping speed | 70L/S | Work power | 12Kw |
| Control mode | Automatic/ Manual | Ultimate vacuum | 20-80 Pa |
| Heating mode | SD320 Heat by oil | Temperature control mode | PID Control |
| Maximum temperature | 180℃ | Temperature uniformity | ±1.5 Multi-point temperature control |
| Work temperature | 100℃～160℃ | Controllable temperature precise | ≤±0.8(at the regulated set temperature value |
| Unevenness of the worktable | Unevenness≤200μm/m² | Air discharge speed | Can adjust continuously within 0～50L/S |
| Press of compressed air | 0.5～0.8MPa | Flow volume of compressed air | 420～800L/S |
| Pumping time | 5～7min | Laminate time | about 20min |
| Work vacuum degree | 80～20Pa | Max. Laminate Thickness | 28mm |
| Cylinder Stroke length | 400mm | Ambient temperature | 0～50℃ |
| Note: Customized specifications are available upon your requirements. | |||
